Introduction of RHD M80 Electric Minivan
KEYTON RHD M80 Electric minivan is a smart and reliable model, with advanced ternary lithium battery and low noise motor. It has a range of 260km with 53.58kWh battery. Its low energy consumption will save as much as 85% energy compared with a gasoline vehicle.
Parameter (Specification) of M80 Electric Minivan
■ Basic parameters |
|
Vehicle dimensions (mm) |
4865×1715×2065 |
Wheelbase (mm) |
3050 |
Wheel base (front/rear) (mm) |
1460/1450 |
Seating capacity (seats) |
11(2+3+3+3) |
Tire specifications |
195R14C8PR |
Minimum ground clearance (full load) (mm) |
155 |
Minimum turning radius (m) |
6 |
Maximum speed (km/h) |
90 |
Curb weight (kg) |
1750(估算数据) |
GVW(kg) |
2683 |
Endurance mileage/km(CLTC) |
260 |
0-50km/h acceleration time (s) |
≤10 |
Maximum gradability % |
≥20 |
■ Motor parameters |
|
Type of motor |
Permanent Magnet Synchronous Motor |
Rated power/torque/Speed (kW/ N.m/rpm) |
35/90/3714 |
Peak power/torque/Speed (kW/ N.m/rpm) |
70/230/3000~7000 |
■ Battery parameters |
|
Type of battery |
Lithium Iron Phosphate (LFP) |
Battery brand |
CATL |
Battery capacity (kWh) |
53.58 |
Battery fast charge (min)SOC30% to 80% |
≤30min |
Battery Fast Charge (h)SOC30% to 100% |
≤14.4(3.3KW)/≤7.2(6.6KW) |
Low temperature battery heating system |
● |
Charging ports |
GB |
■ Braking, suspension, drive mode |
|
Braking system (front/rear) |
Front disc/back drum |
Suspension system (front/rear) |
McPherson independent suspension Leaf spring type non-independent suspension |
Drive type |
Rear-rear-drive |
